| SIZE |
| Max Print Width |
44 inch wide (1118 mm) |
| PRINT TECHNOLOGY |
| Print Head |
2.64" PrecisionCore TFP |
| Print Modes |
Uni & Bi-directional |
| Nozzle Configuration |
9600 nozzles (400 nozzles x 24 channels x 1head) |
| Maximum Resolution |
2400 dpi x 1200 dpi |
| Min Droplet Size |
3.5 pl |
| INK SYSTEM |
|
| Family |
Epson Ultrachrome® XD3 |
| Type |
All-Pigment Aqueous |
| Colours |
C+M+Y+MK+PK+Red |
| Cartridges |
350 ml or 700 ml ink cartridges |
| PERFORMANCE (per Sheet) |
| Print Speed (CAD) |
| A0 Plain Paper |
28s Draft | 43s Speed |
| A1 Plain Paper |
16s Draft | 23s Speed |
| Print Speed (Poster) |
| B0 Photo Paper |
152s Speed | 281s Quality | 614s Max Quality |
| A1 Plain Paper |
35s Draft | 46s Speed | 258s Quality |
 Figures represent print times only for test sample images as shown produced on plain paper and Epson Premium Gloss Photo Paper 170 gsm. Results on alternative media types may vary. Additional processing time may be required with individual results likely to vary depending on print mode, software, operating environment, media, data file size/type. |
| MEDIA SUPPORT |
|
| Roll Format |
Dual roll front loaded spindle, 2" core, 3" (plain paper only), 0.07 to 0.8 mm thick, 254-1,118 mm wide, 170 mm max diameter, 12.5kg max weight |
| Sheet Format |
Top loaded A4-B0 single sheets, 0.07 to 0.8 mm thick, 203-1,118 mm wide.
Front loaded poster board 0.8 to 1.5 mm |
| Borderless Print |
254, 300, 330, 356, 406, 432, 500, 508, 515, 594, 610, 700, 728, 841, 914, 1030, 1118 mm widths |
| Auto Cutter |
Inbuilt rotary type |
| Output |
Sheet or Roll-2-Roll (2nd roll can be configured as an ATU)
Integrated media basket |
| OPERATION |
|
| Control Panel |
4.3" Colour LCD touch screen |
| Control Code |
ESC/P Raster, HP/GL/2 & HP-RTL*
Adobe Postscript Level 3 |
| Connectivity |
USB 3.0 & Ethernet 10Base-T/100Base-TX/1000Base-T, WiFi, WiFi Direct |
| Included Software |
Mac/Windows Printer Driver, MS Office Plug-In, EpsonNet Config, EpsonNet Print (Win only), PS driver, PS folder |
| Software via web download |
HDI driver, CopyFactory, EpsonNet SetupManager, Epson Device Admin, Epson Edge Dashboard, LFP Accounting tool, Epson Media Installer, Epson Print Automate, Epson Cloud Solution PORT |
| Software Compatibility |
Compatible with a range of design, production, workflow management and RIP software |
| Roll Management System (Roll Format) |
Barcode Roll Media Management system helps keep track of the type of media and how many metres is left on the roll |
| USB Input |
Front panel USB slot enables PDF, JPEG and TIFF files to be printed direct from a thumb drive |
| Compatibility |
Windows 10/8.1/8/7/Vista/XP, Mac OSx10.6.8 or later, MacOS 11 or later |
| Networking |
IPv4 & IPv6 addressing, IPsec, IEEE902.1X and SSL/TLS support
NFC Card Reader slot (card not included) |
| Memory |
4 GB + 4 GB RAM (embedded in HW and Adobe PostScript unit) + 960 GB optional SSD |
| Physical (WxDxH) |
1848 × 499 × 975 mm, 155 kg (no ink, media or options)
|
| ENVIRONMENT |
|
| Operational Temp |
10° to 35° C |
| Operational Humidity |
20 to 80% (40 to 60% is recommended for no condensation) |
| Power Supply |
100 - 240 V AC, 50/60 Hz |
| Power Consumption |
70 W Operating, 32 W Standby, 2 W Sleep |
| Operating Noise |
50 dB |
| SHIPPING INFO |
|
| Packaging (WxDxH) |
1,984 ｘ 750 ｘ 1,199 mm, 195 kg
|
| What’s in the Box |
Printer, Power Cord, set of 240 ml ink cartridges, Standard and Borderless Maintenance Tanks, Setup Guide & Warranty Info. Driver, user software & manuals on CD. |
| Delivery & Install |
Some assembly and configuration may be required. A significant proportion of the included ink will be required to ‘prime’ the printer and it is recommended that an additional set be purchased for production work. Delivery, de-boxing and package removal is not typically included but can be provided at an additional charge for most locations. |
| Service & Support |
Support and Service is provided via authorised Epson authorised Large Format Technical Dealers. If you have a problem with a SureColor Technical printer, a related option or consumable please contact your dealer for initial problem evaluation. Should a printer require service this will be provided by on-site free of charge within the period covered by your Warranty and any optional CoverPlus Service Pack. Note: Provision of service and support is subject to Large Format Printer Warranty and CoverPlus terms with the latter conditional on activation of Epson Cloud Solution PORT and connection of the printer. Additional travelling charges may apply for equipment located outside major metro areas. |
| CONFIGURATION OPTIONS |
| C11CH83401 |
T7760D with 1Yr On-Site Warranty |
| SCT7760D3YR |
T7760D with 2Yr CoverPlus On-Site Service Pack (total 3 yrs cover)** |
| SCT7760D5YR |
T7760D with 4Yr CoverPlus On-Site Service Pack (total 5 yrs cover)** |
** Epson CoverPlus Service Packs enable basic warranty cover to be extended. One or more Service Packs can be ordered in conjunction with the various printer configurations &/or options to enable cover for 1, 2, 3, 4 and 5 year periods (total cover cannot exceed 5 years). Operation of CoverPlus on this model requires activation of Epson Cloud Solution PORT and connection of the printer.
Service and support is only provided for product supplied through Epson Australia and New Zealand. This facility is provided in conjunction with the Authorised Large Format Reseller through which the product is ordered. Limitations apply to the provision of warranty upgrades and on-site service. Regional locations and certain installation situations may attract additional charges. Service may be restricted or limited when equipment is used outside of specification &/or with non-Epson consumables. For full details on coverage, terms and limitations please review the warranty terms listed on this web-site and contact Epson or one of our Authorised Large Format Resellers if you have questions or concerns. |
| OPTIONAL ACCESSORIES |
| C12C936671 |
960 GB SSD |
| C12C936171 |
Additional 44” Roll Feed Spindle |
| RELATED PRODUCTS |
|
| SC-T3465 |
24” Single Roll Technical Printer |
| SC-T5465 |
36” Single Roll Technical Printer |
| SC-T5460 |
36” Single Roll Technical Printer with MFP functionality |
| |
|
| *HP-GL/2 and HP-RTL are trademarks of Hewlett-Packard Company. Printer may not print HP-GL/2 or HP-RTL (CMYK type not supported for the latter) language data accurately depending on your system environment or type of print data use. In order to ensure correct printing results, please make sure that you run a printing test prior to deciding on purchasing the printer. Ask your local Epson representative or Epson authorised reseller for your test. |
