Epson's new generation linehead, inkjet label press with LED UV curing ink, the L-6534VW, enables high-speed printing that's ideal for producing labels and packaging with outstanding scratch and weather resistance. The new generation heat-free PrecisionCore® linehead, center drum system, and digital varnish deliver high-quality images. The space-saving, compact design integrates all of the functions required for production, such as Corona treatment, White ink, digital varnish, and an additional UV curing unit.
KEY FEATURES & BENEFITS
- High productivity – high speed print of up to 50m/min
- High image quality – Epson heat-free PrecisionCore printhead offers outstanding print quality
- High stability – Nozzle Verification Technology and automatic cleaning system reduces maintenance and down time
- Value added printing – high density white ink and digital varnish ink enhances colour reproduction
- Wide range of applications – Epson UV ink and Corona treater supports wide range of substrates for different applications
Pinning technology offers ultra high-quality images. White ink and digital varnish printing dramatically increase the range of applications. The Epson-developed pinning technology controls the range of ink scattering and realizes ultra sharp dots and incredibly thin lines. The Epson digital-quality color gamut, tonal gradation, flat print and lack of graininess help those in the prime label industry overcome their hesitation to using UV ink. Now UV printing can be used in more discriminating areas such as health and beauty, nutraceuticals, and food and beverage, as well as standard consumer packaged goods such as car polish, lawn and garden care, and household cleaner labels. In White ink printing, Surface-White Print and Reverse-White Print are available to extend the range of expression on clear and metalized films. With the brand-new digital varnish ink, a gloss or matte finish can be selected for the overall label, and appealing partial accents can even be added using glossy or matte spot varnish.
Printhead: High-quality image printing with the heat-free PrecisionCore linehead
The new generation heat-free PrecisionCore linehead inkjet technology enables high-speed, single-pass printing, complemented by Epson's original ink and ink systems. Designed for optimal performance, the SurePress L-6534VW offers highly engineered, quality printing and superb reliability. The Epson digital monitoring system maintains high productivity using Nozzle State Analysis to manage dropped inkjet nozzles, allowing the job to complete. As Epson's most advanced printhead technology, heat-free PrecisionCore delivers our renowned, industry-leading output quality and durability, even at high speeds.
Ink: Epson's original LED UV curing ink
Quick-drying UV ink boosts productivity and offers excellent weather, scratch, chemical, and water resistance, so it's suitable for printing labels used in severe environments such as the outdoors. A small, long-life LED light source is used, saving space, offering an energy-saving solution, and enabling printing on heat-sensitive substrates such as PE.
Substrate Feed: Center drum system
The center drum system feeds the substrate with incredible precision to minimize color unevenness and reduce the heat expansion or shrinkage of the substrate, enabling various types of off-the-shelf standard flexographic substrates to be used.
Eco Features: SurePress L-6534VW reduces the impact on the environment
The SurePress L-6534VW digital printer enables much easier adjustments than analog printers, minimizing ink consumption and paper waste. Furthermore, the need for the printing plates and cleaning chemicals utilized by analog presses is eliminated. When using only the LED curing system, energy is reduced compared to that used by conventional UV lamps. Epson’s ink facilities meet GMP regulations (EC) 2023/2006, as well as USFDA cGMP. Ink is compliant with FDA, EuPIA, FSVO, EFSA, and EC organizations.
ORANGE INK OPTION
Epson-print-quality UV inkjet press with ultra-wide colour gamut
The Epson SurePress L-6534VW with orange ink comes with the same Epson print quality of the L-6534VW, but with new orange ink to allow for a wider colour gamut verified by PANTONE® certification. Incorporating PrecisionCore® printhead technology and high-pigment, low-migration LED UV curing ink, the press’s centre drum system is a space-saving, compact design. It integrates corona treatment, White Ink, web cleaner, ionizer and an additional UV curing unit, all standard. (Product Code: C11CH31303)
The Epson-developed PrecisionCore printheads, UV inks and LED UV pinning technology control the range of ink placement and realize ultra sharp round dots, which produce incredibly thin lines. In addition, the L-6434VW with Orange Ink has a high gamut ratio, resulting in Epson-quality labels that deliver a wide colour gamut, tonal gradation, flat print and lack of graininess using fewer colours. This also minimizes the number of printheads used. The printer achieves up to 92% of the full PANTONE® range, with a colour difference of less than 1.5 Delta E 2000, well within the standard for PANTONE® validation.
L-6534VW without orange ink
L-6534VW with orange ink
