| SIZE |
|
| Max Media Width |
64 inch (1625.6mm) |
| PRINT TECHNOLOGY |
| Print Head |
10 channel PrecisionCore™ TFP with VSDT |
| Print Modes |
Uni & Bi-directional |
| Nozzle Configuration |
360 x 2 per colour |
| Maximum Resolution |
720 x 1440dpi |
| INK SYSTEM |
|
| Family |
Epson Ultrachrome® DS |
| Type |
Dye Sublimation |
| Colours |
C+Y+M+Bk / C+Y+M+HDk |
| Supply |
4 x 1.5L Continuous Ink Supply System (CISS) |
| Refills |
1L packs (shipped in individual colour cartons of 6x1L) |
| PERFORMANCE |
| Normal Mode Draft |
58.9m2/hr 1 Pass 360 x 720dpi |
| Normal Mode Fast Production |
30.3m2/hr 2 Pass 720 x 720dpi |
| Normal Mode Production 1 |
22.2m2/hr 3 Pass 720 x 720dpi |
| Normal Mode Production 2 |
16.2m2/hr 4 Pass 720 x 720dpi |
| Normal Mode Production 3 |
11.1m2/hr 6 Pass 720 x 1440dpi |
| Normal Mode Production 4 |
8.2m2/hr 8 Pass 720 x 1440dpi |
| HQ Mode Production 1 |
13.8m2/hr 4 Pass 720 x 720dpi |
| HQ Mode Production 2 |
9.4m2/hr 6 Pass 720 x 1440dpi |
| HQ Mode Production 3 |
6.9m2/hr 8 Pass 720 x 1440dpi |
| Speeds shown are bi-directional engine only for 64" wide output. They are provided for reference only; different RIPs may not offer all modes/speeds and some may offer alternatives not listed in the above. Total job throughput times will depend on a number of factors including workflow, paper type, RIP, file format & size, print resolution, ink coverage, networking, heat press equipment, etc. |
| MEDIA SUPPORT |
|
| Format |
Single roll with 2" or 3" core, 250mm max diameter & 40Kg max weight |
| Thickness |
0.08-1mm (75gsm or greater) |
| Width |
300-1625.6mm |
| Margins |
5mm left & right (10mm when using media holding plates) |
| Loading |
Spindle-less, single operator rear mounting with ATC |
| Output |
Sheets (manual cutting) or rolls with +/2.5mm winding accuracy on the ATU |
| OPERATION |
|
| Control Panel |
2.5” Colour LCD |
| Interface |
High Speed USB 2.0 & Ethernet 100Base-T/1000Base-T |
| Included Software |
Epson Edge Print, Windows Communications Driver, EpsonNet Setup, EpsonNet Config. and EpsonNet Print (CD), and Epson LFP RemotePanel2 (Web download) |
| Optional Software |
Ergosoft RIP Version 15 (Epson Essential or Production Editions)
Additional compatible software |
| Memory |
512 MB Main + 128MB Network |
| Media Output Heater Modes |
Selectable temperature (Off, 30° to 55°C) |
| ENVIRONMENTAL |
|
| Operational Temp |
15°-35° (15°-25° recommended when using HDk ink) |
| Operational Humidity |
20 to 80% with no condensation (40-60% recommended) |
| Power Supply |
5A, 240V, 50/60 Hz AC |
| Power Consumption |
460W Operating (heater on), 10W Sleep (heater off, 1000Base-T Interface) |
| Operating Noise |
59dB |
| PHYSICAL |
|
| Printer (with CISS, no ink) |
2620 x 1013 x 1314mm (WxDxH), 274kg |
| Recommended Operation Space |
3.6 x 2.9 x 1.8m (WxDxH) |
| Packaging |
Printer: 3.12 x 1.09 x 0.86m, 320Kg
Stand & CISS: 3.10 x 1.06 x 0.64m, 135Kg
Printer & Stand boxes must be shipped straight & level
Media is shipped separately
Starter ink must be ordered separately |
| WHAT'S IN THE BOX |
|
Printer, Substrate Support System (SSS), Power Cords, Continuous Ink Supply System (CISS), 1 x 64" Roll of Epson Transfer Media, 1 x Waste Ink Bottle, 1 x Maintenance Kit, Epson Edge Print Software (CD), Installation/Safety manual, Utility & User manual (CD). Some configurations include additional Ergosoft RIP software (Epson Essential or Production Editions).
Ergosoft is one of the world’s premier RIP solutions for fabric, soft and hard signage work. The software features an advanced RIP engine with precision colour management. The Epson Edition has been configured specially for the SureColor-F series with custom drivers and features normally only available as optional add-ons. The F7200 can be ordered with the Essential or Production versions. The Essential version is designed for flexible high-quality ad-hoc work. It includes features such as Tiling & Shrinkage Correction, no-gap Repeat Printing, Custom Linearization, Automatic Colour Replacement, Image add-ons, Position Templates & Image Pre-sets. The Production version is designed for premium and high volume work. It includes all the feature of the Standard package with additional Colour Profiling, Job Costing, Proofing, Ticketing, Quality tracking, Step & Repeat printing, and Hot Folder batch processing. Both versions provide support for a range of file formats including Postscript II/III, PDF (X-3), EPS, AI TIFF, BMP, PNG & JPEG. |
| SYSTEM REQUIREMENTS |
|
A Personal Computer will be required for installation and operation of this printing system. The PC should have a minimum Intel Core i3 /AMD Phenom 2 or equivalent processor (2.5Ghz i5 or greater with separate GPU recommended), 8GB or more memory, a 250GB or larger HDD (1TB recommended), running Windows Vista 32bit or greater (Win 7 64bit/Win 8 recommended). A DVD drive with +/-RW read support and a network with external Web access will be required for installation. For optimum performance it is recommended that 1000Base-T Ethernet networking be employed. High speed web access and an off-line storage facility with DVD+/-RW write support is recommended for operation with the ErgoSoft RIP.
The use of a 3rd party ancillary heater/ blower unit is recommended with this machine, particularly for high speed work. The typical operational environment will also involve either a flat or calendar style heat press of appropriate size. Please speak with your dealer for recommendations. |
| CONFIGURATION OPTIONS |
| SCF72001Y |
Printer with 1Yr Warranty |
| SCF72003Y |
Printer with 1Yr Warranty & 2Yr CoverPlus On-Site Service Pack (3 yrs cover in total)** |
| SCF72005Y |
Printer with 1Yr Warranty & 2 x 2Yr CoverPlus On-Site Service Pack (5 yrs cover in total)** |
| SCF7200ESS1Y |
Printer with 1Yr Warranty & ErgoSoft RIP (Essential Edition) |
| SCF7200ESS3Y |
Printer with 1Yr Wty, & 2Yr CoverPlus On-Site Service Pack** (3 yrs total on-site service cover) & ErgoSoft RIP (Essential Edition) |
| SCF7200ESS5Y |
Printer with 1Yr Wty, & 2 x 2Yr CoverPlus On-Site Service Packs** (5 yrs total on-site service cover) & ErgoSoft RIP (Essential Edition) |
| SCF7200PRO1Y |
Printer with 1Yr Warranty & ErgoSoft RIP (Production Edition) |
| SCF7200PRO3Y |
Printer with 1Yr Wty, & 2Yr CoverPlus On-Site Service Pack** ( 3 yrs total on-site service cover) & ErgoSoft RIP (Production Edition) |
| SCF7200PRO5Y |
Printer with 1Yr Wty, & 2 x 2Yr CoverPlus On-Site Service Pack** ( 5 yrs total on-site service cover) & ErgoSoft RIP (Production Edition) |
| ACCESSORIES & OPTIONS |
| C12C890941 |
Bk Starter Ink Pack – 4 Colour x 1L |
| C12C932111 |
HDk Starter Ink Pack – 4 Colour x 1L |
| 1YWF7200 |
1Yr CoverPlus On-Site Service Pack** |
| 2YWF7200 |
2Yr CoverPlus On-Site Serive Pack** |
| SERVICE & SUPPORT |
|
| **Printers are covered by a comprehensive 1 year warranty that covers all non-consumable parts (Including Print Heads) & labour with free-on-site service in all metro areas (regional locations will attract an additional travelling charge). Cover can be extended up to a maximum of 5 years through purchase of optional CoverPlus packages. Important: Cover may be restricted or denied if the user does not perform maintenance & cleaning as outlined in the user guide &/or advised by Epson Australia or New Zealand, if equipment is used outside of specification &/or with non-Epson consumables. Please refer to the warranty section of this web site for details and contact Epson or one of our Authorised Resellers if you have questions. |
| |
|
