Back catalogue – Epson TM-T88 ReStick

KEY FEATURES & BENEFITS
  • Prints on both receipt and liner-free label paper
  • High-speed printing – For graphics, barcodes and text
  • High quality and reliability
  • Fully TM-T88 compatible
  • Uses repositionable adhesive liner-free MaxStick labels
  • Easy drop-in paper loading
  • Vertical and horizontal mounting options available

Cost-Effective Liner-Free Label Printing
Epsons liner-free label printing solution, using adhesive label paper, is significantly less expensive than using a standard label printer. There is no need to peel off and dispose of a paper liner, reducing both cost and waste.

Easy Integration
Epsons TM-T88 ReStick label printer can be easily integrated into your current systems. It is compatible with Epsons existing TM-T88 printers, so almost no software changes or application development is required.

Just install the driver and its ready to go. And with Epsons exclusive of interfaces, the TM-T88 ReStick is compatible with all current best-of-breed and component-based systems.

MAXStick Liner-Free Labels Epsons liner-free label printing solution, using MAXStick adhesive label paper, is significantly less expensive than using a standard label printer.

Without the need for a coated paper liner, the cost of supplies is greatly reduced and there is no waste. There is also no need to inventory various sized rolls due to MAXStick labels being variable in length.

  • Will stick to a wide range of surfaces
  • Will stick over and over again
  • Will not damage the surface it sticks to
  • Will not leave residue behind which could result in paper jams and/or print degradation

Typical Liner-Free Label Applications
Epsons liner-free ReStick label printer is a cost-effective solution for a wide range of label applications used in the fast food, hospitality and convenience industries including:

  • Exception labels
  • Bag tag labels
  • Product labels
  • Pizza Box labels
  • Sandwich wrap labels
  • Speciality cup labels
  • Take-away order labels
  • Delivery receipt labels
  • Nutritional labels, etc

Label Printers

PRINTER
MODEL NAME TM-T88 ReStick Label Printer
PRINT METHOD Thermal line printing
PRINT RESOLUTION 203 dpi x 203 dpi
PRINT FONTS
PRINT SIZE
(Font A/B/C)
80mm: Normal mode (203 dpi) 12 x 24/9 x 17/10 x 24;
Emulation mode (180 dpi) 13 x 24/10 x 17/10 x 24.
COLUMN CAPACITY
(Font A/B/C)
80mm: Normal mode (203 dpi) 48/64/57 columns;
Emulation mode (180 dpi) 44/57/57 columns.
CHARACTER SIZES
(Font A/B/C) (W x Hmm)
80mm: Normal mode (203 dpi) 1.25 x 3.0/0.88 x 2.13/1.125 x 3.0;
Emulation mode (180 dpi) 1.25 x 3.0/0.88 x 2.13/1.125 x 3.0.
CHARACTER SETS 95 Alphanumeric, 48 International, 128 x 11 Graphic (including user-defined page)
BARCODES UPC-A/E, CODE 39/93/128, EAN8/13, ITF, CODABAR, 2D symbols: PDF417, QR-CODE
PRINTER
INTERFACES RS-232C, IEEE 1284 parallel; high-speed USB; 10/100Base-T/TX; wireless (optional)
DATA BUFFER Receive: 45 bytes or 4KB, selectable; user-defined: 12KB; macro: 2KB; NV graphics: 256KB; NV user: 1KB
POWER 24 VDC ± 7%
POWER CONSUMPTION Approx. 1.8 A (mean)
D.K.D. FUNCTION 2 drivers
COLOUR Epson Dark Grey (EDG)
FACTORY OPTIONS Power supply cover, PS-180 AC adapter, wall hanging bracket, affixing tape and various interfaces
OVERALL DIMENSIONS 145mm (W) x 195mm (D) x 148mm (H)
WEIGHT 1.8Kg
CONTROL BOARD
EMI AS/NZS CISPR22 Class B
SAFETY STANDARDS UL60950-1
CSA C22.2 No. 60950-1
FONT EMULATION TM-T88 series (180 dpi) font emulation available
PRINTER SPECIFICATIONS USING MAXStick LINER-FREE LABEL PAPER
ReStick LABEL PAPER Print speed (max.)
Paper dimensions
150mm graphics and text
79.4 ± 0.4 (W) x 76.2 +3.8/-1.6 mm dia.
RELIABILITY MTBF
MCBF
Autocutter
360,000 hrs
48,000,000 lines
600,000 cuts
RECOMMENDED MAXStick® LINER-FREE LABELS 80mm paper width model Part number: MS318150
PRINTER SPECIFICATION USING NORMAL RECEIPT PAPER
RECEIPT PAPER Print speed (max.)
Paper dimensions
177mm/sec graphics and text
79.5 ± 0.05 (W) x 83mm dia.
RELIABILITY MTBF
MCBF
Autocutter
360,000 hrs
52,000,000 lines
1.5 million cuts
dpi: dots per 25.4 mm (dots per inch)


Optional power supply case
secures cords under printer

Epson is the registered trademark of Seiko Epson Corporation. Epson trademarks of Seiko Epson Corporation. All other names and company names used herein are for identification purpose only and may be the trademarks or registered trademarks of their respective owners. Epson disclaims any and all rights in those marks. All print samples shown herein are simulations. Specifications are subject to change without notice.
