Back catalogue – Epson M-T123

Impact Mini Printers |
|||
PRINTER | |||
---|---|---|---|
PRINTING METHOD | Thermal Line | ||
NUMBER OF TOTAL DOTS | 384 dots / line | ||
RESOLUTION | 8 dots / mm | ||
PRINTING WIDTH | 48 mm | ||
PRINTING SPEED | 50 mm / sec. max. (at 7.5 V) | ||
PAPER FEEDING PITCH | 0.0637 mm | ||
PAPER END | Photosensor | ||
PRINTING TEMPERATURE | Thermistor | ||
PRINTHEAD UNLOAD | Microswitch | ||
POWER SUPLY VOLTAGE | |||
PRINTHEAD & MOTORS | 5.0 to 8.0 VDC | ||
PRINTHEAD CONTROL & SENSOR | 5 ± 0.25 VDC | ||
CONNECTOR | |||
MOTOR | FFC | ||
PAPER DIMENSIONS | 57.5 ± 0.5 mm (W) x dia.80 mm | ||
OPERATING TEMPERATURE | 0 to 50°C | ||
RELIABILITY | |||
PRINTHEAD LIFE | 50 km, 100,000,000 pulses | ||
MCBF | 15,000,000 lines | ||
PRINTER LIFE | 6,000,000 lines | ||
OVERALL DIMENSIONS | 82.4mm (W) x 50.2mm (D) x 14mm (H) | ||
WEIGHT | Approx. 65 g |
