Back catalogue – Epson M-T200 Series

Impact Mini Printers
PRINTER M-T203 M-T207A
PRINTING METHOD Thermal line Thermal line
NUMBER OF TOTAL DOTS 432 dots / line 432 dots / line
RESOLUTION 8 dots/mm 8 dots/mm
PRINTING WIDTH 54mm 54mm
PRINTING SPEED 80 mm / sec. max. (at 24 V) 100 mm / sec. max. (at 24 V)
PAPER FEEDING PITCH 0.063mm 0.063mm
PAPER FEEDING SPEED 80 mm / sec. max. (at 24 V) 100 mm / sec. max. (at 24 V)
PAPER END Photosensor Photosensor
PRINTHEAD TEMPERATURE Thermistor Thermistor
PRINTHEAD UNLOAD Microswitch Microswitch
POWER SUPLY VOLTAGE M-T203 M-T207A
PRINTHEAD AND MOTORS 24 VDC ± 2.4 V 24 VDC ± 2.4 V
PRINTHEAD CONTROL & SENSOR 5 ± 0.25 VDC 5 ± 0.25 VDC
CONNECTOR M-T203 M-T207A
PRINTHEAD MOTOR FFC FFC / 4-pin connector (cutter motor)
PAPER DIMENSIONS 57.5 ± 0.5 mm (W) x dia.83 mm 57.5 ± 0.5 mm (W) x dia.83 mm
PAPER THICKNESS 60 ~ 75 μm 60 ~ 75 μm
OPERATING TEMPERATURE 0 to 50°C 0 to 50°C
RELIABILITY M-T203 M-T207A
PRINTHEAD LIFE 50 km, 50,000,000 pulses 50 km, 50,000,000 pulses
MCBF 15,000,000 lines 15,000,000 lines
PRINTER LIFE 6,000,000 lines 6,000,000 lines
OVERALL DIMENSIONS 76.9mm (W) x 174.5mm (D) x 164.8mm (H) 84.3mm (W) x 196.3mm (D) x 113.8mm (H)
WEIGHT Approx. 350 g (Take-up Paper Holder) Approx. 410 g (Paper Holder)
CONNECTOR (A/C SENSOR) M-T203 M-T207A
A/C LIFE 600,000 cuts 600,000 cuts
A/C METHOD Scissors type Scissors type
A/C DURATION Approx. 400 ms Approx. 400 ms
