Home Theatre Projection Perfected

Brilliant Brightness. Crisp Colour. Dramatic Detail.

Epson Home Theatre 4K PRO UHD*

4K PRO-UHD Projector* with HDR10

2,600 Lumens White Brightness

2,600 Lumens Colour Brightness

Precision Cinema Lens Technology

* 4K Enhancement Technology (4Ke) shifts each pixel diagonally to double the native panel Full HD (1920×1080) resolution. Resolution is Full HD in 3D Mode.

Epson new type of 4K home theatre projection technology logo

A new type of 4K home theatre projection technology. And it's only from Epson.

With proprietary dedicated processors for resolution enhancement, HDR, and image processing – the result is incredible brightness, colour accuracy, and image detail – faithfully displaying all your favourite content from the classics to the latest blockbusters.

The most important aspects of visual performance, handled with dedicated hardware.

Epson Projector 3 dedicated processors for 4k resolution enhancement, image processing and HDR processing

Epson Projector Exceptional 4K Experience

Dedicated 4K Resolution Enhancement Processor

Advanced 4K pixel-shifting hardware precisely controls three-individual high-definition LCD chips to parallel process up to 12 million pixels of information. This new type of resolution enhancement technology results in an exceptional 4K visual experience – surpassing virtually all other forms of 4K home theatre projection.

Epson Dedicated Digital Imaging Processor

Dedicated Digital Imaging Processor

Real-time 12-bit analog-to-digital video processing ensuring smooth tonal transitions, while eliminating banding, blocking, and other compression artifacts from the final visual performance. This powerful processor faithfully reproduces the source material the way it was intended to be shown.

Epson Dedicated HDR Processor

Dedicated HDR Processor

Full 10-bit HDR colour processing accepting 100% of the HDR source information to faithfully reproduce HDR content for an exceptional visual performance.

Image Divider

Unique 3-Chip Projection Technology

3LCD Projection Engine - Designed by Epson

The proprietary 3LCD Projection Engine is one of the reasons why Epson is considered the world leader in high-resolution projection technology. A true 3-Chip design, Epson 3LCD technology utilises three-individual LCD chips for each colour of RGB. The result? Incredible brightness, colour accuracy, and image detail – for an exceptional home theatre experience.

Epson 3-Chip Projection Technology
image divider

Extreme Colour Gamut.

One of the first commercially available home theatre projectors capable of displaying the full three-dimensional DCI-P3 colour space. This extreme colour performance is 50% wider than typical 1-Chip Rec. 709 projectors and allows for a truly professional-level of colour accuracy.

image divider

Introducing the Epson Precision Cinema Lens

Advanced Projection Lens Technology only from Epson

Designed specifically for high-definition 4K HDR content, Epson precision lenses utilise Extra Low Dispersion (ED) Glass optics for exceptional brightness, colour accuracy and image detail.

Epson Advanced Projection Cinema Lens Technology

Unique 15-Element Aspheric Glass Structure (AGS)

Epson precision cinema lenses feature a unique 15-Element Aspheric Glass Structure (AGS) that shifts the focal plane to the inside of the lens structure itself. Not only does this ensure surface dust is not visible on the final projected image but provides outstanding overall brightness and focus uniformity.

blue dash image divider

Optimal Modulation Transfer Function (MTF)

Epson precision cinema lenses are designed around optimising the Modulation Transfer Function in order to ensure superior resolving power at any zoom level. This not only maximises the performance of our unique 3LCD Projection Engine but ensures a professional-level of colour accuracy while eliminating virtually any chromatic aberration.

blue dash image divider

Precision Manufactured by Epson

The lens is a critical component within the overall projector design. This is why Epson decided to develop the precision cinema lenses in partnership with some of the world's greatest lens manufacturers. Utilising an advanced form of fusion & cooling, Epson precision cinema lenses combine over 100 raw materials into pristine glass lens structures – rivaling some of the world's most precise lenses.

blue dash image divider

Extreme Focus Uniformity

Utilising advanced manufacturing processes allows the Epson precision cinema lenses have up to 35% better Focus Uniformity than virtually any other projection lens available today. The result? Epson precision cinema lenses are capable of faithfully displaying the source material without reducing image brightness or detail.

Epson 3-Axis Projector Precision Motorised Lens

3-Axis Precision Motorised Lens

Ideal for precise installation and fine adjustments, Epson precision lenses include a fully-powered Zoom, Focus, and Lens Shifting Technology. With ten custom presets, you can store and retrieve preset lens positions on the fly.

Epson 4K Home Entertainment Projector Lens Features

Precision-built Light Source

Epson Digital Lamp Projection

Epson Digital Lamp Projection is unique within the industry. The key to utilising lamps to provide the main light source within a projector is to precisely control the wavelength of light being delivered by the lamp itself.

In order to precisely control the wavelength of light being delivered, Epson engineers specifically designed the lamp and the 3-Chip Projection Systems to work together. Not only does this deliver a more consistent visual performance from the projector, but ensures the correct colour of light is used within the Epson 3LCD Projection Engine. This results in outstanding overall colour and white brightness performance, while optimising overall lamp life.
