SureColor G9060

64" DTFilm Production Printer
epson promotion icon

DIRECT-TO-FILM PRINTER
PRODUCT NAME SureColor G9060
SIZE
Max Media Width 64 inch (1,625 mm) wide
PRINT TECHNOLOGY
Print Head 2.64" PrecisionCore® MicroTFP with VSDT
Nozzle Configuration Total nozzles: 9,600 nozzles
  • CMYK: 6,400 nozzles（1,600 nozzles x 4 colours
  • Wh: 3,200 nozzles
Maximum Resolution 1200 x 1200 dpi
Features Variable Sized Droplet Technology
Epson Precision Dot Technology
Continuous ink-less nozzle status monitoring
Self-cleaning printhead (fabric based)
Advanced self-cleaning capping system
Continuous white in circulation
Front loaded consumables and rear media loading
User-replaceable printhead
Bulk waste system
INK SYSTEM
Family Epson Ultrachrome® DF
Type Direct-to-film (DTFilm)
Colours CYMK + White + Maintenance Liquid
Supply 6 x 1.6L Pouches
Loading Tray system
PERFORMANCE
Max Speed 68.8 sqm/hr 1 layer 600 x 600 dpi
34.1 sqm/hr 2 layer 600 x 600 dpi
Fast Production 45.5 sqm/hr 1 layer 600 x 600 dpi
  23.1 sqm/hr 2 layer 600 x 600 dpi
Standard Production 34.4 sqm/hr 1 layer 1200 x 600 dpi
  16.1 sqm/hr 2 layer 1200 x 600 dpi
Quality Production   17.4 sqm/hr 1 layer 1200 x 600 dpi
  8.6 sqm/hr 2 layer 1200 x 600 dpi
High Quality Production   13.7 sqm/hr 1 layer 1200 x 1200 dpi
  6.7 sqm/hr 2 layer 1200 x 1200 dpi
Speeds are based on 1,625mm wide output produced using Epson Edge Print PRO. 1 layer prints assume output in either white or CMYK only while two layer printers assume output with both a white layer and a CMYK layer. Figures are provided for reference only and are subject to change. Actual performance will depend on the individual user application/ quality requirement. Total throughput times will depend on a number of factors including workflow, media width, RIP, file format & size, print resolution, ink coverage, networking, cleaning cycles and powder applicator / oven equipment. Customers are recommended to undertake print tests and confirm performance prior to purchase.
MEDIA SUPPORT
Format Single roll with 2" or 3" core, 250 mm max diameter, 45 kg max
Thickness Up to 0.5 mm
Width 300 - 1,625 mm (11.8" ~ 64")
Minimum Margins 3 mm left & right
Loading Roll unit, rear mounting
Output Continuous roll- based production is supported when used with appropriate powder applicator/oven equipment
OPERATION
Control Panel 4.3" Colour with touch interface
Interface Super Speed USB & Ethernet 100Base-T/1000Base-T
(Ethernet recommended)
Memory 2 GB
Included Software Epson Edge Print PRO via Web download
Fiery Digital Factory Epson Production Edition
Epson Cloud Solution PORT with integrated costing functionality via
(Web service & free App download)
Minimum System Requirements Windows 10/11 (64bit) or later
Multicore 3.0GHz or faster Processor
8GB RAM, 50GB HDD
(For optimum performance a higher spec’d processor, additional RAM and a larger HDD or SSD is recommended)
Physical Printer Footprint 2.50m2
Operational Space (W x D x H) Back : 1,000 mm clearance for roll setup.
Front and both sides: 500 mm clearance for cutting and media setup.
Workspace: 9.27 2
Operational Temp 10 ~ 35° C (20 ~ 25° C recommended)
Operational Humidity 20 to 80% (40 ~ 60% recommended) with no condensation
ENVIRONMENTAL
Power Supply 240 V, 50/60 Hz AC, 5 A
Power Consumption 440 W Operating, 70 W Ready, 42 W Sleep
Operating Noise 56 dB
PHYSICAL (W x D x H)
Printer 2949 x 844 x 1605 mm, 370 kg (no ink or media)
Packaging Printer: 3300 x 1130 x 1080 mm, 415 kg
Roll Unit: 2422 x 668 x 613 mm, 35 kg
Bulk Ink Solution: 606 x 94 x 912 mm, 67 kg
Inks (each: 180 x 403 x 41 mm, 2 kg)
WHAT'S IN THE BOX
Printer, Stand, Power Cord, a set of CMYKW+Ml 1.6L ink pouches, 1 x Roll Unit, 1 x Bulk Ink Solution, 1 x Reusable 4L Waste Ink Bottle, 1 x Ink charging tool, 1 x Head Cleaning Kit, 1 x Maintenance Kit, Epson Edge Print PRO License, Fiery Digital Factory Epson Production Edition Licence, warranty sheet and Set-Up guide. User manual and software provided via web download.

NOTES: Film and powder need to be sourced separately. Sheet- based production will require a suitable oven and for optimal productivity a powder applicator may be considered. Roll- based production will require a suitable shaker/oven unit. A heat press will be required with either configuration to enable image transfer onto the final media.
CONFIGURATION OPTIONS
SCG90601Y 5c Printer with 1 year service cover
SCG90603Y 5c Printer with 3 year service cover
SCG90605Y 5c Printer with 5 year service cover
SERVICE & SUPPORT
Printers are covered by a comprehensive 1 year warranty that covers all non-consumable parts (including the Print Head) & labour with free-on-site service in all metro areas (regional locations will attract an additional travelling charge). Cover can be extended up to a maximum of 5 years through purchase of optional CoverPlus either with the printer or up to 365 days subsequent to purchase (discounts apply for bundled purchase).

Important: Warranty and CoverPlus may be restricted or denied if the user does not perform maintenance & cleaning as outlined in the user guide &/or advised by Epson Australia or New Zealand, if equipment is modified, used outside of specification &/or with non-Epson consumables. CoverPlus on this model requires activation of Epson Cloud Solution PORT and connection of the printer to the service. Please refer to the Warranty and CoverPlus sections of this web site for full details and contact Epson or one of our Authorised Resellers if you have questions.
