Epson EB-1776W

Epson EB-1776W

Corporate Portable Multimedia Projectors

The Ultra Mobile, Ultra Bright Solution for Busy Executives



Its ultra-slim design, radiant widescreen performance and easy wireless connectivity make the Epson EB-1776W the ultimate choice in portable projectors. It delivers value, convenience and performance. The EB-1776W easily delivers HD video content or images from your widescreen notebook with native WXGA (1280 x 800) resolution. Couple that with 3000 lumens colour / white light output and the results are truly amazing.

KEY FEATURES & BENEFITS
  • Easy to use Features Including Full Automatic* Setup – Simply turn on the power and leave the rest to the projector.
  • Smallest 3,000 Lumen, 3LCD projector in the world – Only 45mm thick, and 1.71kg in weight.
  • Wireless 802.11b/g/n – Included standard with the EB-1776W.
  • iProjection – Display and control content from your iPhone®, iPad® or iPod® touch with the Epson iProjection App and any nearby wireless or networked Epson projector.
  • USB Plug ‘n Play – Transmit Images, Sound and Mouse Operation through one USB cable.
  • DICOM Simulation Mode – Specialised imaging uses standardised greyscale to reproduce medical images such as x-rays for medical training and education.
  • Low Total Cost of Ownership – Lamp price only $119RRP.
  • Broad Connectivity – HDMI, VGA, Video (RCA), USB Type B, USB Type A, Audio (stereo mini).
3x Brighter Colours with Epson
3x Brighter Colours with Epson*

Brilliant image quality requires high colour brightness (colour light output), and Epson® 3LCD projectors have 3x Brighter Colours than leading competitive projectors*.

One brightness measurement (lumens) is not enough. A projector‘s specification needs to show both high colour brightness and high white brightness. If colour brightness is lower than white brightness, images may be dark, dull and lose detail. If not be sure to ask for a projector’s colour brightness specification.

* Compared to leading 1-chip DLP business and education projectors based on NPD data, July 2011 through June 2012. Colour brightness (colour light output) measured in accordance with IDMS 15.4. Colour brightness will vary depending on usage conditions.

Easy-To-Use

The Epson EB-1776W was designed for absolute ease of use. Simply turn on the power, direct the projector towards the screen or wall and the image is automatically adjusted with any vertical keystoning corrected. The EB-1776W is even able to correct horizontal keystoning, focus, and where the projected image extends beyond the screen or whiteboard the user need only press the "screen fit" button and the EB-1776W will automatically resize the image to match with the edges of the screen, adjusting focus at the same time. All this in less than 4 seconds. Simple! In line with the screen aspect of most notebook PCs, the EB-1776W can project in a native WXGA widescreen aspect, meaning no complications. Simply connect, and project!

Network and Wireless Capability

With the EB-1776W you can remove the need for untidy, complicated cabling, and connect to your 802.11b/g/n wireless network via the ELPAP07 wireless LAN module. For added simplicity, the ELPAP08 USB Quick Wireless Connection Key enables users to make a quick peer to peer connection to a PC.

iProjection

Display and control content from your iPhone®, iPad® or iPod® touch with the EPSON iProjection App and any nearby wireless or networked Epson projector. Whether projecting a PowerPoint® presentation loaded to the iProjection App or a photo slideshow from your iPad, Epson's iProjection gives you the wireless freedom you've come to expect from your mobile device. This App is easy to use and navigate with intuitive menu options that make it simple to bring your iOS content to the big screen.

USB Plug ‘n Play and USB Memory Slide Show

The EB-1776W can display your presentation with image, audio and mouse control via a connection to a PC or Mac with a simple USB cable. You can also create and display images directly from a USB memory device, making it possible to give presentations without the need for a PC.

Low Power Consumption – EuP Compliance

At Epson, we know that planning for the future requires a strong commitment to the environment.  That’s why these products conform to the new European Directive on Eco-Design of energy using products.  The main objective of this directive is to ensure energy efficiency throughout a product’s lifecycle.  Each of the models in the EB-1700 series conform to the criteria of this directive.

Direct Connect to ELP-DC06

Further enhancing suitability to the modern corporate environment is the ability for the EB-1761W to connect directly to the Epson ELP-DC06 document camera / visualiser. These Epson products feature unique technology enabling them to connect via USB and provide full operation without the need for a PC.

DICOM Simulation Mode

DICOM (Digital Imaging and Communication in Medicine) is a standard for handling, storing, printing, and transmitting information in medical imaging, which includes a file format definition and a network communications protocol. The DICOM simulation mode in the EB-1761W can reproduce images with gray level very close to DICOM Part 14 (Grayscale Standard Display Function). This mode is ideal for viewing grayscale medical images such as X-ray pictures for training and education in the medical institutions.

Split Screen

Project two images (video or still) side-by-side from two different sources simultaneously. Choose from three layout options. You can swap the images as well as choose the source for audio.

Real time Auto H/V keystone correction

With Epson’s real time keystone correction, you can project a rectangular image from almost any Angle on the go. The EB-1776W automatically corrects the image if the projector is moved, ensuring your presentation is always front and centre.

PDF Viewer and Movie Playback

Users can display PDF or motion JPEG files saved to a USB flash drive directly from the projector, no conversion needed.



Connectivity Panel
